WSM-315(PNE61-315P)

Feature code:

Characteristics:

● IGBT inverter technology

● Wide range of power supply

● Good product consistency

● Pulse frequency is adjustable

● With variety of TIG operation mode

● High frequency arc ignition, welding penetration well

● Performance stable, strong anti-interference ability

● Thermal design is reasonable to protect the machine perfectly

● Digital display for current to accurate preset welding current before welding

● With MMA function (200A above model)

● Two TIG mode: DC TIG or Pulse TIG
●DSP digital welding machine;
●RS-485 communication socket match RC-6,RC-7 remote controller;

● The welding cables can be lengthened to 50~100M/50mm2


Model

WSM-315

Company type

PNE61-315P

Rated input voltage(V)

3 phase  380V±15%  50~60Hz

Rated Input capacity (KW)

17

No-load voltage (V)

60±5%

Output current adjusting range(A)

5~315

Pulse frequency (Hz)

0.1~500

Thrust current range(MMA)

0~1500A/ms

Slope up time (s)

0.1~99.9

Slope down time (s)

0.1~99.9

Spot time (s)

0.01~9.99

Pre-flow time (s)

0~13

Post-flow time (s)

0.1~50

Pulse ratio range

0.1%~99%

Duty cycle (40℃)

60%

Power factor

0.93

Efficiency

85%

Insulation grade

F

Case protection grade

IP21S

Cooling

Wind

Dimensions (mm)

560×300×530

Net weight (kg)

34
